SSH
KEY TAKEAWAYS
- Ubuntu has the latest version of the OpenSSH client installed by default.
- All the tools needed to secure and customize the SSH daemon are built in.
- You can use terminal tools like tmux and screen to log into devices and manage SSH sessions.
- You can use GUI tools like SecureCRT, Termius, and putty. See SSH GUI clients
I highly recommend buying a copy of SSH Mastery by Michael Lucas. It’s available at SSH Mastery or Amazon as an ebook for about $10.
When I switched to Linux my only experience with SSH was Putty. Basically just opening putty, putting in an ip address and connecting. I knew that Putty had a separate program, puttygen, to create ssh keys and other functionality but I really just used it to do a simple ssh connection. There is so much more to SSH and Michael explains all of it in SSH Mastery.
For a network engineer the biggest benefit of Ubuntu is that you have an SSH client and server that can be used from the terminal without installing proprietary software. It gets updated automatically when Ubuntu is updated.
As I moved more and more to NetDevOps and started working with Linux servers in the cloud I started to appreciate the benefits of having an ssh client and server integrated with the operating system.
History of SSH
Secure Shell (SSH) has always been an open source project. It was originally released in 1995 by a Finnish computer scientist Tatu Ylönen. Before SSH, telnet was the most popular remote access protocol but it doesn't support encryption.
OpenSSH was released in 1999 by the OpenBSD project. Most network devices supports SSH V1 and V2. V1 has been deprecated and V2 was released in 2006. On network devices if you do a show ip ssh command you might see SSH Enabled - version 1.99 which means both V1 and V2 are enabled. What you want to see is SSH Enabled - version 2.0 meaning V1 is disabled.
The open source community for ssh and ssl are moving rapidly to drop support for legacy ciphers.
Warning
Ubuntu 25.04 includes openSSH 9.9p1 which dropped all support for ssh V1! Any device that uses ssh-dss for the Host Key Algorithm will not connect
I upgraded to Ubuntu 25.04 on my laptop because I wanted some features in Gnome 48. The openSSH 9.9p1 update turns out a problem for older network devices like an HPE Procurve 2920, a Cisco IOS-XE device running 3.6.7 or older or a Ubiquiti M5 NanoStation. The reason is they are using ssh-dss for the Host Key Algorithm. This was part of the ssh V1 spec so it is gone.
I tried to recompile openSSH using flags but they were serious and there isn't a way to add ssh-dss back. This means that you cannot open a terminal and ssh to an older network device.
Work Around for ssh-dss
- You can install putty using
sudo snap install puttysince putty brings legacy crypto with it. - You can spin up a virtual machine of Ubuntu 24.04 using KVM.
I installed Putty but then realized that I use netmiko and other tools so I had to install a VM. I will glad when ancient network equipment is gone. Just last week (June 2025) a friend texted me that he was at a customer with a working Cisco 4500 running CatOS and Cisco 2926 switches. Gemini couldn't figure out how old these devices were!
Verifying ssh ciphers
From a terminal you can use:
- ssh -V - Display openSSH version
- ssh -Q HostKeyAlgorithms - Display the Host Key Algorithms supported
- ssh -Q MACs - Display the Message Authentication Code algorithms supported
- ssh -Q KexAlgorithms - Display the Key Exchange Algorithms supported.
I created the following alias since I was checking often and on several machines:
alias mw-ssh='ssh -V && echo "" && echo HostKeyAlgorithms && ssh -Q HostKeyAlgorithms && echo "" && echo MACs && ssh -Q MACs && echo "" && echo KEXAlgorithms && ssh -Q KexAlgorithms'
I preface my custom aliases with "mw" so that I can type mw- and hit tab to display them.
This is the output on Ubuntu 25.04
mw-ssh
OpenSSH_9.9p1 Ubuntu-3ubuntu3.1, OpenSSL 3.4.1 11 Feb 2025
HostKeyAlgorithms
ssh-ed25519
ssh-ed25519-cert-v01@openssh.com
sk-ssh-ed25519@openssh.com
sk-ssh-ed25519-cert-v01@openssh.com
ecdsa-sha2-nistp256
ecdsa-sha2-nistp256-cert-v01@openssh.com
ecdsa-sha2-nistp384
ecdsa-sha2-nistp384-cert-v01@openssh.com
ecdsa-sha2-nistp521
ecdsa-sha2-nistp521-cert-v01@openssh.com
sk-ecdsa-sha2-nistp256@openssh.com
sk-ecdsa-sha2-nistp256-cert-v01@openssh.com
webauthn-sk-ecdsa-sha2-nistp256@openssh.com
ssh-rsa
ssh-rsa-cert-v01@openssh.com
rsa-sha2-256
rsa-sha2-256-cert-v01@openssh.com
rsa-sha2-512
rsa-sha2-512-cert-v01@openssh.com
MACs
hmac-sha1
hmac-sha1-96
hmac-sha2-256
hmac-sha2-512
hmac-md5
hmac-md5-96
umac-64@openssh.com
umac-128@openssh.com
hmac-sha1-etm@openssh.com
hmac-sha1-96-etm@openssh.com
hmac-sha2-256-etm@openssh.com
hmac-sha2-512-etm@openssh.com
hmac-md5-etm@openssh.com
hmac-md5-96-etm@openssh.com
umac-64-etm@openssh.com
umac-128-etm@openssh.com
KEXAlgorithms
diffie-hellman-group1-sha1
diffie-hellman-group14-sha1
diffie-hellman-group14-sha256
diffie-hellman-group16-sha512
diffie-hellman-group18-sha512
diffie-hellman-group-exchange-sha1
diffie-hellman-group-exchange-sha256
ecdh-sha2-nistp256
ecdh-sha2-nistp384
ecdh-sha2-nistp521
curve25519-sha256
curve25519-sha256@libssh.org
sntrup761x25519-sha512
sntrup761x25519-sha512@openssh.com
mlkem768x25519-sha256
Notice there are no ssh-dss ciphers
This is the output on Ubuntu 24.04. You can see ssh-dss on lines 18-19.
Locating devices with ssh-dss Host Key Algorithms
You can use nmap to quickly scan devices and find those with ssh-dss ciphers.
nmap -sV -p 22 -oN ssh-dss.nmap --script ssh2-enum-algos 192.168.10.50-254
The -oN ssh-dss creates a .nmap file.
Here is the output from the HPE 2920 in my garage:
Since we created the nmap file we can use:
grep -i '192.168|dss' ssh-dss.nmap to quickly find all devices.
Here is a sample output:
As you can see, devices 192.168.10.51-52 are using ssh-dss as the Host Key Algorithm. I have my network devices registered in DNS to it's easy to identify them. If you use MS Windows you can easily ask chatGPT to create a PowerShell script to read a spreadsheet of hostnames/IP addresses and create the DNS entries.
The HPE 2920 is running WB.16.10.0025 firmware which I think is the last release. Here is a show ip ssh from the 2920:
You can see from the ip ssh config that you can change the cipher and the MAC but not the Host Key Algorithm. FYI, HMAC is Hashed Message Authentication Code. All ssh MACs are actually HMACs.
What Cryptographic Algorithms Should I use
When building a configuration template for a deployment you should remove as many legacy ciphers as possible. As the US CISA pushes for more secure IT infrastructure you will find more customers running security scans after you deploy. It's better to pass a security scan than have to answer questions about why your refresh failed a basic security audit.
Since SSH is almost 30 years old there are a lot of ciphers available. But of course, many are no longer secure. IoT manufactures and network devices typically have a lot of ancient ciphers. Episode 209 of the 2.5 Admins podcast titled: Faulty Defaults is worth listening to if any of this is new to you.
Asking which ciphers are secure is like asking "Is Mac better than Windows?". But here are some general guidelines:
- Don't use any encryption with CBC in the name. For example aes128-cbc. The CBC means
cipher block chainingand PCI will fail you if it finds it. - Do use encryption with CTR in the name. For example aes256-ctr.
- Don't use a MAC with SHA1 in the name if possible. For example hmac-sha1
- Do use a MAC with SHA2 in the name. For example hmac-sha2-256 or hmac-sha2-512
- Don't use a Key Exchange Algorithm (KEX) with SHA1 in the name if possible. For example diffie-hellman-group1-sha1
- Don't use a HostKeyAlgorithm with dss in the name. This is an SSH V1 Host key and has been dropped on openSSH 9.9 and above.
You can do a search on the Internet for current algorithms. But, you will find that a lot of network devices don't support modern cryptographic algorithms. Some notable exceptions that support modern ciphers are:
- Aruba CX version 10.07 and newer
- Juniper Junos version 18.2R1.9 or higher
- Cisco IOS version 15.2(7)E2 or higher
- Cisco IOS-XE 17.2.x or later
How to configure the algorithms
This is not an exhaustive tutorial. It's here to give you an idea of how to configure ssh algorithms for your base template.
Aruba CX
ssh ciphers chacha20-poly1305@openssh.com aes256-ctr aes256-cbc
ssh host-key ed25519
ssh host-key-algorithms ssh-ed25519 ecdsa-sha2-nistp521
ssh key-exchange-algorithms ecdh-sha2-nistp256 curve25519-sha256
diffie-hellman-group-exchange-sha256
ssh macs hmac-sha2-256 hmac-sha2-512
ssh public-key-algorithms x509v3-ssh-rsa rsa-sha2-256
ssh maximum-auth-attempts 5
The Aruba CX firmware has rock solid cryptographic algorithms out of the box. See the link in the references below for the exact algorithms. For a table of ssh server commands, see the Aruba CX SSH server commands below.
Cisco IOS
ip ssh version 2
crypto key generate rsa modulus 4096 label SSH-KEYS
ip ssh rsa keypair-name SSH-KEYS !associate keys to SSH
ip ssh server algorithm encryption aes256-ctr aes192-ctr aes128-ctr
ip ssh server algorithm mac hmac-sha2-256 hmac-sha2-512
no ip ssh server algorithm mac hmac-sha1
no ip ssh server algorithm mac hmac-sha1-96
ip ssh authentication-retries 5
Ciscco IOS XE
ip ssh version 2
crypto key generate rsa modulus 4096 label RSA4096_SSH_KEY
ip ssh rsa keypair-name RSA4096_SSH_KEY !associate keys to SSH
ip ssh server algorithm authentication keyboard
ip ssh server algorithm mac hmac-sha2-512 hmac-sha2-256
ip ssh server algorithm encryption aes256-gcm aes256-ctr
ip ssh server algorithm kex ecdh-sha2-nistp521 ecdh-sha2-nistp384
ip ssh server algorithm hostkey rsa-sha2-512 rsa-sha2-256
ip ssh server algorithm publickey ecdsa-sha2-nistp521 ecdsa-sha2-nistp384
ip ssh authentication-retries 5
Juniper
set system services ssh ciphers aes256-ctr
set system services ssh macs hmac-sha2-256
set system services ssh macs hmac-sha2-512
set system services ssh hostkey-algorithm ssh-ed25519
References SSH History
- Secure Shell Wikipedia
- Top 20 OpenSSH Server Best Security Practices
- Aruba CX SSH ciphers
- IOS-XE SSH Best Practices
- Configuring IOS XE for Strong Security SSH Sessions
Connecting to Network Devices
KEY TAKEAWAYS
- Ubuntu makes it easy to use SSH from the terminal
- You can create custom entries in the ssh config file for each device if needed
- You can use password authentication or public key authentication with the ssh client
- You can easily create a jump host and secure your network devices even further.
To connect using ssh:
- Open the terminal
- Enter the following command.
ssh mhubbard@192.168.10.253
Change the username and IP address to fit your device.
Run network commands remotely
You can run commands remotely on the network device using ssh. For example, to execute show running-configuration use:
You can also use shell commands to get just what you need. For example, let's say I want to know what ip ssh commands are in the running configuration.
Network Devices with legacy ciphers
One problem for a network engineer is that newer versions of the OpenSSH client don’t allow weak crypto by default and most network devices have weak ciphers by default. If you are connecting to network devices from a modern version of Mac/Linux you will probably get an error and the connection will fail. You will have to customize the ~/.ssh/config file to add the ciphers needed.
This is an example trying to connect to a Cisco 3850 IOS XE switch running 16.12.3a:
Unable to negotiate with 192.168.10.253 port 22: no matching key exchange method found. Their offer: diffie-hellman-group14-sha1
Here is the entry I added to ~/.ssh/config:
Open the file using gnome-text-editor ~/.ssh/config and add the following:
You can add an SSH key file and a custom port for ssh if needed:
To use a specific key on the fly:
ssh -i ~/.ssh/customer1/id_rsa 192.168.10.253
I have run across network devices that required the ancient dss HostKeyAlgorithm. Add that with:
HostKeyAlgorithms +ssh-rsa,ssh-dss
Using a wildcard in the config file
If you have 100s or 1000s of devices with legacy crypto it gets painful to create an entry in ~/.ssh/config for every device. You can use a wildcard in the configuration file that will pass the same configuration to every connection. Keep in mind that the wildcard configuration applies to all devices that match the wildcard, not just network devices.
If you have a dedicated management network, for example, 192.168.10.0/24:
The + sign adds the legacy ciphers but leaves the new ciphers in place. So a device that only has legacy ciphers can connect but a new device should still negotiate new ciphers.
You can use the ? as wildcard placeholders. For example, 192.168.10.?? would match any host address with 2 digits.
You can also put multiple hosts on the same line, separated by spaces.
host 192.168.10.* 172.16.1.*
You can use an * to cover any hosts. The ~/.ssh/config file is read top to bottom so you can place this at the bottom and have specific devices defined above it.
Create an ssh config file for testing purposes
You can use a different configuration if you want to test changes without modifying ~/.ssh/config. Use -F option, for example:
ssh -F test-config 192.168.10.253
Use a different username for network access
Let's say that your laptop's username is mhubbard but the customer uses vector on all network devices. You can add the username to your config file:
Now list the username on my laptop
Log into the switch and run who:
This is very convenient even if you are not using ssh keys.
Display the configuration that will be used
Using -G Causes ssh to print its configuration after evaluating Host and Match blocks and exit. You can review your settings to verify you’re getting what you need.
In this example I removed a lot of detail but you can see the key that will be used, the ciphers, and other important details. The -G switch will save you a lot of time preparing you config file.
SSH Jump hosts
A jump host is a device that you connect to and then connect to other devices. This is done to limit administrative access to just the jump host. This is very easy to do with Linux. Spin up an Ubuntu server VM with a NIC that has access to the network devices, hardened per your company security policy and then add ProxyJump to the ssh config file.
In this example I have an Ubuntu server at 192.168.10.223:
The !192.168.10.223 parameter means not 192.168.10.223. Without this entry there would be a loop and the jump would fail.
Now use the - J option:
None of your keystrokes reach the jump host. The only thing the jump host can see is an encrypted data stream between your client and the destination server.
Note
Keep in mind that if the jump box is down you will not be able to log into the network devices. If you use ssh -v you will see these messages:
- debug1: Reading configuration data /Users/mhubbard/.ssh/config
- debug1: /Users/mhubbard/.ssh/config line 4: Skipping Host block because of negated match for 192.168.10.223
- debug1: /Users/mhubbard/.ssh/config line 18: Applying options for *
You can comment out the ProxyJump 192.168.10.223 line in the configuration with a # symbol until the jump box is back online.
References Wild Cards
SSH config wildcard on expanded Hostname
Debugging SSH connections
You can use the -v switch to debug the SSH connection. You can repeat the v up to 4 times - -vvvv. Each extra v adds more details to the output.
What crypto does my device support?
On most switches you can use something like show ip ssh to get a list of the current ssh ciphers.
Here is an example from the Cisco 3850 in my home lab:
Checking ciphers with nmap
For devices that don't have show ip ssh, like IoT devices, you can use nmap with the built in ssh-enum-algos script. This is from the Ubiquiti Nano Station in my home lab.
As you can see, it has good crypto like curve 25519 and aes256-ctr but then it also supports rsa-dss and diffie-hellman group1 sha1! Why?
This is an example of why you don't want to use the wildcard in the configuration file. depending on the client you could end up using sha1 instead of sha2 or ssh-dss instead of ssh-rsa.
nmap also has a similar script for checking SSL (TLS) crypto:
For new deployments you should take the time to remove legacy crypto in the switch configuration that you build. Once you decide on the best setup, add it to your base template. This is a best practice and will save you some embarrassment if the customer has a security team. Don't ask me how I know this.
If you have written permission from the network owner, you can use this script to do a quick cipher suite assessment of the existing network devices. I have a python script that creates a menu of nmap scripts for security testing. You can find it here. The script is easy to use has a lot of nmap goodness for a network engineer.
SSH GUI Clients
Here are three different GUI SSH clients for Linux.
Putty
If you are coming from Windows you have probably used Putty. There is a Linux version of putty that is free to use.
Installation
You can install putty using the Ubuntu package manager:
sudo apt-get install -y putty
sudo apt-get install -y putty
[sudo] password for mhubbard:
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following additional packages will be installed:
putty-tools
Suggested packages:
putty-doc
The following NEW packages will be installed:
putty putty-tools
0 upgraded, 2 newly installed, 0 to remove and 6 not upgraded.
Need to get 1,240 kB of archives.
putty --version
putty --version
PuTTY: Release 0.78
Build platform: 64-bit Unix (GTK + X11)
Compiler: gcc 13.2.0
Compiled against GTK version 3.24.38
Source commit: 4ff82ab29a22936b78510c68f544a99e677efed3
Notice that it's a fairly old version. Tap the Super key and type putty to run it. I would not install it, instead use ssh from terminator or purchase Termius/SecureCRT.
Termius
Termius is a modern SSH client and terminal that works on:
- Windows
- Mac OS
- Linux
- IOS
- Android
Which makes it a great option. I personally use it on all of those except Windows. It syncs to the cloud so no matter what device I am on I have all of my hosts, keys, etc. It also has color coding for most network devices and a lot of themes.
I bought it years ago when it was in beta. It's now a $10.00 per month subscription. I think it's worth $10 per month but you will have to decide for yourself.
Installation Termius
go to download and select Download .DEB then open a terminal and run sudo dpkg -i Termius.deb
SecureCRT
This is the 800lb Gorilla of SSH clients. If your company pays for a license for Windows users, you should be able jump on that plan. If not it's $209 for a three year subscription or $129 for a 1 year subscription.
I have never used SecureCRT so I am just going to put a link to the download here and you can research it yourself.
Installation SecureCRT
Creating SSH Keys
The OpenSSH client allows you to create custom SSH keys. You can create as many keys as you need. You should think about your security requirements and create SSH keys to fit the requirements. For example, if you work for a VAR or MSP, you may want to create unique keys for each customer. You can create subdirectories for different customers. For example:
~/.ssh/customer1/
See the section Network Devices with legacy ciphers for an example of how to add a key to a device profile.
My current recommended public-key signing algorithm is Dan Bernstein's ED25519. To create a set of keys using ed25519, run the following in the terminal from the ~/.ssh directory:
ssh-keygen -a 100 -f id_custom_25519 -o -t ed25519 -C "$(whoami)@$(uname -n)-$(date -I)"
-a 100 Use 100 rounds of pbkdf2 (password based key derivation function 2).
-f name for the key pair.
-o Use the new RFC4716 key format and the use of a modern key derivation function powered by bcrypt.
-t Specifies the type of key to create. The options are:
- dsa (weak)
- ecdsa
- ecdsa‐sk
- ed25519
- ed25519‐sk
- rsa (weak)
dsa and rsa are not good choices as they are deprecated. The keys with -sk at the end are for use with physical Security Keys. See the Yubico topic later in this section for more information.
-C Specifies a comment to be added to the public key to make it easier to identify the key in the authorized_keys file of the server you connect to. This is optional. In the example:
- whoami - The username
- uname -n - The device hostname
- date -I - The year-month-day
Specify a strong passphrase when prompted. The passphrase is required anytime you use the key. If you don’t password protect the key, and an attacker gets access to the keys, they can log into any server you used them on.
Here is what the output of the command should look like:
Here is what the public key looks like with the comment:
You can see my username (mhubbard), hostname (1S1K-G5-5587) and date at the end.
You can replace any of the variables between the starting " and ending ". For example instead of hostname you could use key-4-cisco:
"$(whoami)-key4cisco-$(date -I)"
Display the existing keys on Ubuntu
Tip for naming keys
I always start my key names wih id_. If you don't, you will need to modify the ~/.ssh/id_* section of the next command.
for keyfile in ~/.ssh/id_*; do ssh-keygen -l -f "${keyfile}"; done | uniq
- DSA or RSA 1024 bits: This is a red flag. Unsafe.
- RSA 2048: This is a yellow flag, recommended to change
- RSA 3072/4096: Good, but ED25519 is better!
- ECDSA: depends. Recommended to change
- ED25519: The best choice!
Here is what it looked like on my laptop.
You can see the comment on the first key.
You can print the file name out by adding a print statement:
SSH Key permissions
The private key should have rw permission to only the user. No other users or groups should have any permissions. Use the following to view/set the permissions:
Here is the output using keys with 0644 instead of 0600:
Using the SSH keys
KEY TAKEAWAYS
- SSH Keys use Public Key Infrastructure (PKI) instead of usernames/passwords. Keys are more challenging to brute force than passwords.
- Linux servers are very easy to configure to use ssh keys on. The
ssh-copy-id -i ~/.ssh/id_rsa.pub <Server_IP>command copies the public key to the server in one step. - Hardware Security devices such as Yubico Yubikey and the Google Titan Security Key allow you to store your keys securely and login from any laptop or desktop.
- Many Network Devices (Cisco, Aruba, Juniper, Arista, Ubiquiti, etc.) support ssh key authentication.
Once you have keys created what do you do with them? If you support Linux servers it's very easy to copy the public key to the server. Using a Public/Private key pair instead of a password to authenticate an SSH session is popular on Linux/Unix boxes. If you spin up a Virtual Private server on Digital Ocean or Linode you will want to use keys instead of a username and password.
Digital Ocean, a Virtual Private Server (VPS) provider, has this advice on how you should log into their Droplets: "you should use public key authentication instead of passwords, if at all possible. This is because SSH keys provide a more secure way of logging in compared to using a password alone. While a password can eventually be cracked with a brute-force attack, SSH keys are nearly impossible to decipher by brute force alone." Plus, it means you never have to type C!$c0 again!
See Brute Forcing SSH below for an example of brute forcing ssh with nmap.
SSH Keys with a Linux server
Following along with our id_custom_25519 example and an Ubuntu server at 192.168.10.223:
You can see how the comment makes the key easy to identify in the authorized_keys file.
Since we created a passphrase for the key we are prompted for the passphrase, then logged in.
Automatic logins
If you need to have an automated login, you can create a key without a passphrase. The actual connection is still secure, but if you lose control of the private key anyone can use it. It's one of those religious arguments that exit in security circles.
Alternatively, you can add the ssh private key to the ssh agent using the following command:
ssh-add ~/.ssh/id_custom_ed25519
You will be prompted for the passphrase.
ssh-add switches
You can find all switches using man ssh-add. Here I'm listing the more common switches.
- D Deletes all identities from the agent.
- d Deletes the given identities from the agent. The private key files for the identities to be deleted should be listed on the command line.
- K Load resident keys from a FIDO authenticator.
- k When loading keys into or deleting keys from the agent, process plain private keys only, skipping certificates.
- L Lists public key parameters of all identities currently represented by the agent.
- l Lists fingerprints of all identities currently represented by the agent.
- X Unlocks the agent. This asks for a password to unlock.
- x Locks the agent. This asks for a password; the password is required for unlocking the agent. When the agent is locked, it cannot be used for authentication.
Be sure to ask your security team if using the ssh-agent is permitted.
I get an error when trying to use the key
If the login fails, rerun the ssh command with -vvvv ssh -vvvv 192.168.10.253. If you see a debug message sign_and_send_pubkey: signing failed: agent refused operation the first time you use the key enter the following:
ssh-add to add the default private keys to the ssh agent and
ssh-add ~/.ssh/id_custom_ed25519 to add our custom key.
You can view the keys in the agent using:
For the first key you can see the size, 4096 bits, the fingerprint, the label we used when creating the key and the type (RSA).
References ssh-add
SSH Keys with github
Github doesn't accept username/password for repositories any longer. You will need to use a key pair and configure git to use it. I created a key pair just for github named id_github. To add it to your global git configuration:
Once you have the key configured in the ~/.gitconfig file you will need log into github.com, settings, SSH and GPG keys, and click "New SSH key".
Using SSH keys with network devices
First off why would you want to use ssh keys on switches/routers/etc? With large customers you typically use Cisco ISE, Aruba Clearpass or Microsoft Network Policy Server (NPS) and authenticate to Microsoft AD.
But with smaller customers you may not have these infrastructure services available. Using SSH keys on switches/routers/etc when ISE, Clearpass or NPS isn't available is better than using local users and passwords. In this situation, over time, the customer will usually have several different usernames and passwords across different switches and it can be a nightmare to log into all the switches.
They may not even have the credentials for all devices. In that case, you may want to use the nmap ssh-brute script. See Brute Forcing SSH below for an example of brute forcing ssh with nmap.
If you add your public key to the network devices before deploying, at least you will be able to log in efficiently without wasting time trying different passwords. You can also give the private key to the customer and they can import it into Putty.
Using SSH keys with a Cisco IOS switch
Unfortunately it's not quite as easy to enable key based login on network devices but it's just a process. You can include it in your basic security template for example and automate it.
I'm using a WS-C3850-48U running 16.12.3a CAT3K_CAA-UNIVERSALK9 for this example.
Configure a Time Server
Accurate time is required to use ssh keys. The first step is to configure a time server.
The no ntp allow mode control 3 is a Cisco recommended best practice to prevent DOS attacks.
- ntp allow mode control 3 --> causes the device to respond to mode 6 packet with a delay of 3 seconds, hence rate limiting and being considered not vulnerable (recommended)
Check NTP server config with nmap
nmap has two built in scripts for checking the NTP server configuration.
sudo nmap -sU -p 123 -n --script=ntp-monlist 192.168.10.253
sudo nmap -sU -p 123 --script ntp-info 192.168.10.253
The first one is for verifying that your ntp server doesn't support the "Monitor List" command that led to serious DDoS attacks back in 2014. Here I ran it against the ntp server on the Cisco 3850:
Notice the only output is that the port is open. If the switch supported "monitor list" it would have returned a list of devices that have requested time.
The second is very useful when you are having time issues. You can run it against the configured time server and see if you get response. I have an alias setup for this script:
Here I ran it against my Cisco 3850 after I configured it for time.
To verify that the switch is syncing with the ntp server I configured:
Add a Domain Name, create the key, set SSH v2
To enable ssh on the switch you have to create an SSH key pair. I used a modulus of 4096, the maximum. It took 113 seconds to generate! We will copy our RSA public key to the switch's pubkey-chain in the next section. That public key will be used with our private key to secure the SSH session.
ip domain name pu.pri
crypto key generate rsa modulus 4096 exportable label RSA-SSH-Key
ip ssh version 2
ip ssh rsa keypair-name RSA-SSH-Key !associate keys to SSH
Optional but informational
The "exportable" parameter. This isn't required but I wanted to point that out that you can make the keys exportable. It's not so important in this case but if you have setup GetVPN on a router you absolutely want to export the keys used for the tunnels. If you don't and the router fails you will have to touch EVERY tunnel once you replace the hardware. If you have exported the keys you just reload them on the new hardware and call it a day.
Display the key
show crypto key mypubkey rsa RSA-SSH-Key
% Key pair was generated at: 14:15:39 PDT Jul 21 2024
Key name: RSA-SSH-Key
Key type: RSA KEYS
Storage Device: not specified
Usage: General Purpose Key
Key is exportable. Redundancy enabled.
Key Data:
30820222 300D0609 2A864886 F70D0101 01050003 82020F00 3082020A 02820201
009EB39F 14DF98CA 96D74597 E3056C4B A1DD37B3 71019ADC D8FD0AD7 81335E21
D14CC267 79409A66 FD687EA3 312D65A5 E6D14A22 0EE598BC 0991E5FB 91261101
B29BDF85 05058257 8373F9B6 83093E65 ABBCF25C 422965EB 5D84A07D 9E97F8D1
E834BE4B 74970547 42F5C48C BFA3A968 00569467 FA65080B A0F5F8DC 27AFC43C
B00FBAE6 899C8B5C 3B5F6A6A 9F8EC065 C7A50455 6B5D4345 F3CD9B74 C55D0180
F8870094 55A86FDF A514C4BA 74FC2E21 B7F3D7F4 1924847C B420BF2C 4FD14250
C7D40209 914F3FF6 67F2EEEA F4674BDF FF692E36 C73BC4DF 597261D2 80B7FFC3
DAF6E93C C167F196 D1A3B7AE A4B8EFC3 1FB3DA2C 681C1A9F 601F096E 1E73534F
CCE25F9E DC753531 98DADDB1 C6C127E9 033EF061 7EB1DD44 33186410 15D23500
A5569BE0 B1FB1C5F 83C017C2 8C223DD5 C07B3759 816E84B7 D9D6E503 C0A3DDD3
5B3323AE 485744F9 B131422F 45E8DAED CF595280 F8ACE13A E2DFF9BE A75EA8ED
78AB6DB3 52FC940C 40D4AC25 CF976D72 47E51F67 6EC05E8F CB6BEE99 53318C0D
076880F0 A6AE0FD6 950AE9ED B17C5CCE D95209EA CA74B09B 83B103A9 510357CB
D5514EA8 DD71BFC4 C57E7FD6 8EFE80E1 FA6CAADD 751EA11B 7D179394 791CE1BC
71660659 E59E9FA0 9D0A3A0C 078C569D FF3CCB4D 4D6191E6 1A627C1E 64BC9649
C25476B0 610EA0BC 1A124B93 FD6B61BC F5B09D38 427019FD D8D7B5D8 AB0AF723
B5020301 0001
Export the Key
(config)#crypto key export rsa RSA-SSH-Key pem terminal 3des Sup3rS3crt
% Key name: RSA-SSH-Key
Usage: General Purpose Key
Key data:
-----BEGIN PUBLIC KEY-----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-----END PUBLIC KEY-----
-----BEGIN RSA PRIVATE KEY-----
Proc-Type: 4,ENCRYPTED
DEK-Info: DES-EDE3-CBC,067C3CC2D69C7213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-----END RSA PRIVATE KEY-----
Copy the key stating at BEGIN PUBLIC KEY until END PRIVATE KEY, save it to a file and store it in a secure place.
Configure AAA authentication
The aaa new-model command causes the local username and password on the router to be used in the absence of other AAA statements. Once you enter "aaa new-model" you will not be able to enter "login local" on vty line configuration. If you had login local configured it will be removed.
When you create the username be sure to include a secret. If you don't, anyone will be able to login with just the username. As always, create a strong secret and use a password manager to store it.
(config)#username mhubbard privilege 15 algorithm-type scrypt secret ^8(nn-!#who
(config)#aaa new-model
(config)#aaa authentication login default local
(config)#aaa authorization exec default local
(Authentication through the line password is not possible with SSH)
Configure the vty lines
(config)#line vty 0 4
(config-line)#transport input ssh
(config-line)#logging sync (prevents console messages from interfering with your inputs)
Add your PUBLIC key to the device
Open the public key file you created earlier in a text editor (not a word processor). Copy the text between the comments. If you generated a 2048/4096 bit key you will need to break it into smaller pieces or you may see "%SSH: Failed to decode the Key Value" when you exit. I break it into 100 characters per line.
Paste the key into the device
Make sure to press enter after key-string before you paste the key in. You have to use exit to end the key-string input. Then use end to exit configuration mode.
Verify the ssh configuration
Use the hash for setting up the rest of the switches
You can use the HASH instead of the key for the next devices you setup. Instead of using "Key-string" in the ip ssh pubkey-chain statement use key-hash ssh-rsa 5D24EA1D261C1836E437F4E67E2CEBEB.
If you need to remove a key use the no keyword with the key-hash keyword. I needed to remove the old 2096 bit RSA key after I changed the ip ssh dh min key size to 4096.
Login using the SSH Keys
Continuing in the theme of network devices having legacy crypto, you will have to add PubkeyAcceptedKeyTypes +ssh-rsa to the ~/.ssh/config file for the host.
ssh -i ~/.ssh/id_rsa.pub 192.168.10.253
Remember that you can add -vvvv to the command to get verbose debugging. I had to do that because the key was failing. In the debugs I saw send_pubkey_test: no mutual signature algorithm which reminded me to add PubkeyAcceptedKeyTypes +ssh-rsa to the config file for this host.
You can also use ssh 192.168.10.253 and the SSH client will try all the keys. I prefer to explicitly call the key, but it doesn't matter if you don't.
Here is the complete configuration and debug to log into the Cisco 3850 using the id_rsa key:
Once you have entered the passphrase it will be added to the ssh agent and you won't be prompted again until you close the terminal and open a new one. If you want to remove the key from the agent without closing the terminal use:
ssh-add -D ~/.ssh/id_rsa
If you want to change the password on the key use:
ssh-keygen -p -f ~/.ssh/id_rsa
Using keys with Putty
If you want to connect from a Windows computer with Putty I have a blog with a tutorial on how to create keys and connect using putty/puttygen - Authenticating to Cisco devices using SSH and your RSA Public Key.
Can users still login who don't have keys configured?
Yes, the key-chain must be configured for each user.
Here are the users I have configured on this switch:
You can see that thubbard has to use a password but mhubbard can use a password or SSH keys. User mhubbard has two keys listed because I generated keys on my Ubuntu machine and my M1 MacBook Air. I could have copied my private key from Ubuntu to the MacBook but I wanted to show two keys.
Note
IOS only allows two keys in the key-chain.
You can see in the ouput the user's secret is hashed as type 9. In Cisco speak that is scrypt. Scrypt is a memory hard hash so having hardware GPUs doesn't speed up reversing the hash. To create a users with scrypt:
username thubbard privilege 15 algorithm-type scrypt secret Sup3rS3cr3t
Using the keys with a JunOS switch
Setting up the JunOS switch is similar to setting up the Cisco switch.
Using the keys with an Aruba CX switch
The Aruba CX switches are easy to set up for SSH and public key access. They support strong cipher suites and it's easy to reset the cipher suite if you remove some and your client can't connect. I personally think they set the standard for how the SSH server implementation should be done on network devices.
Initial setup
In the Cisco section above we configured NTP, and the user accounts before setting up SSH. You need to do the same for the Aruba CX.
You need to decide which VRF to enable the server on. In this example, we will use the mgmt vrf. Use the following command to enable the ssh server:
When an SSH server is enabled on a VRF for the first time, host-keys are generated. Keeping with the "Aruba sets the standard for ssh" theme, the default RSA key is 4096 bits!
Note
If the host-key of the given type exists, a warning message is displayed with a request to overwrite the previous host-key with the new key.
That isn't a problem as far as setting up ssh, but keep in mind that if you have connected before, the client will complain that the key has changed.
If that happens you will see the following message:
You can copy/paste the following into the terminal to remove the old host:
On macOS you don't get the command to delete the old key but it does give you the line number in the ~/.ssh/config file that you need to delete.
Viewing the host-keys
List the enabled auth methods
Before adding our public key check to make sure publickey authentication is enabled. Public Key Authentication is enabled by default.
Public key authentication can be enabled/disabled using the following:
Add your public key
This is where the Aruba shines! You need to display the public key on your laptop and copy it to the clipboard. In the Creating SSH Keys section we created id_custom_25519, you can use the following commands to view that public key on your computer and copy it to the Aruba:
View the public key
In this example, I have copied the public keys from my Linux and Mac laptops:
That's all that's needed to setup pulic key login on the Aruba CX switches!
List logged in users
I logged into the switch from my Linux and Mac laptops:
Configure Key Exchange
The default key exchange algorithms are good but diffie-hellman-group14-sha1 is available. Since I'm using Ubuntu 24.04 and this switch is in my lab I changed the algorithms using the following. Notice that no comma is used between the algorithms.:
Configure MACs
MAC stands for message authentication code. In SSH it's actually HMAC, or Hash Message Authentication code. The default MACs are good but it does include hmac-sha1 which is weak. Since I'm using Ubuntu 24.04 and this switch is in my lab I changed the MACs using the following. Notice that no comma is used between the macs.:
Configure the Public Key Algorithms
Again, the default public key algorithms are good but it does include ssh-rsa with is weak. Since I'm using Ubuntu 24.04 and this switch is in my lab I changed the MACs using the following. I shortened the list substantially, and I really would just use the ssh-ed-25519 if I had all modern clients in my organization. Notice that no comma is used between the algorithms.:
Final SSH ciphers
Here is what the final ssh server configuration looks like. Notice that Aruba doesn't even offer ssh v1, version 2 has been available since 2006. I have no ideas why Cisco and others still ship it.
Reset cipher suites
You can reset individual cipher components or run all of these to get back to factory default settings.
Aruba CX SSH server commands
The following commands cover everything you need to do to configure ssh.
| Task | Command | Example |
|---|---|---|
| Enabling the SSH server | ssh server vrf | ssh server vrf default |
| Disabling the SSH server | no ssh server vrf | no ssh server vrf default |
| Clearing the list of trusted SSH servers for your user account | ssh known-host remove | ssh known-host remove 192.168.10.130 |
| Configuring SSH to use a set of ciphers | ssh ciphers | ssh ciphers chacha20-poly1305@openssh.com aes256-ctr aes256-cbc |
| Configuring SSH to use a set of host key algorithms | ssh host-key-algorithms | ssh host-key-algorithms ssh-rsa ssh-ed25519 ecdsa-sha2-nistp521 |
| Configuring SSH to use a set of MACs | ssh macs | ssh macs hmac-sha2-256 hmac-sha2-512 |
| Configuring SSH to use a set of key exchange algorithms | ssh key-exchange-algorithms | ssh key-exchange-algorithms ecdh-sha2-nistp256 |
| Configuring SSH to use a set of public key algorithms | ssh public-key-algorithms | ssh public-key-algorithms x509v3-ssh-rsa ssh-rsa rsa-sha2-256 |
| Showing the SSH server configuration | show ssh server | show ssh server all-vrfs |
| Showing the active SSH sessions | show ssh server sessions | show ssh server sessions all-vrfs |
| Showing the SSH server host keys | show ssh host-key | show ssh host-key ecdsa |
| Show state of local password-based (for SSH) and SSH public key authentication | show ssh authentication-method | show ssh authentication-method |
| Copying the client SSH public key into the key list | user authorized-key | user admin authorized-key ssh-ed25519 AAAAC3NzaC1lZD...uxn mhubbard@1S1K-G5-5587-2024-07-08 |
| Removing SSH public keys from the key list | user authorized-key | no user admin authorized-key 2 |
| Showing the SSH client public key list | show user | show user admin authorized-key |
| Configuring SSH idle session timeout | cli-session |
|
Using the keys with an HPE Procurve switch
Colorizing the ssh output
There is a github project called chromaterm that allows you to colorize the linux screen command which allows you to use a USB serial cable with color. Unfortunately that project was discontinued in 2022. It is still available on github if you want to try it out chromaterm
Luckily a new project is available called chromaterm-- and works great with the latest version of Ubuntu. Here is the link chromaterm--
On macOS, it's available from brew using brew install hSaria/tap/chromaterm
For Ubuntu we will clone the repository and install it. I have a directory 04_tools that I use for networking tools. You should make a directory for tools, cd into it and then run:
git clone https://github.com/hSaria/ChromaTerm--.git
cd ChromaTerm--/src/
./configure
sudo make install
Copy the chromatermrc config file into ~/.chromatermrc. The configuration is written in Perl Compatable Regular Expression v2. You can test new regexes using Regex101. Set the FLAVOUR to PCRE2 (PHP >=7.3).
You can also use chatGPT to help you create new regexes. Just tell it you need PCRE v2 regexes and it will create a regex. It will probably be an interative deal to get the regex just right.
I found a good starting configuration file here and then added several Cisco IOS XE regexes.
My config file is at Ubuntu4NetworkEngineers. You can click on the linnk, and copy it. Save it to ~/.chromatermrc
You can use chromaterm with a lot of Linux commands, to use it with ssh simply pipe the output to ct.
ssh 192.168.10.253 | ct
Here is an asciinema recording of chromaterm-- in action.
The OpenSSH Server
KEY TAKEAWAYS
- OpenSSH is a powerful collection of tools for remotely controlling networked computers and transferring data between them.
- OpenSSH includes SCP so you can copy files to and from a network device.
- OpenSSH can use passwords or public keys to authenticate.
Ubuntu comes with an SSH client. If you want to be able to ssh back into your laptop or send files to network devices using SCP you need to install and configure the OpenSSH server. Run these commands to enable the SSH server:
Useful SSH system commands
- sudo systemctl start ssh - Start the SSH server
- sudo systemctl stop ssh - Stop the SSH server
- systemctl status ssh - Show server status
- sudo systemctl disable ssh – disables SSH server after next reboot
- sudo systemctl enable ssh – enables SSH after the next reboot.
Example with OpenSSH installed but not started:
Notice the Active status is inactive (dead).
Example with OpenSSH installed and started:
Notice the Active status is active (running) since Mon 2024-07-15 09:38:12 PDT; 4s ago
You can see the daemon starting, listening on port 22, and then the status of the daemon changes to Started ssh.service - OpenBSD Secure Shell server
I don't use the sudo systemctl enable ssh command because I don't need SSH running all the time. I start and stop it as needed for added security.
Edit the OpenSSH configuration file
The OpenSSH server configuration file is located at /etc/ssh/ssh_config. To edit the configuration file use the following command:
sudo nano /etc/ssh/ssh_config to edit in the terminal
or
sudo gnome-text-editor /etc/ssh/ssh_config if you want a GUI
Tip: Before editing the configuration file, you should make a copy of the original /etc/ssh/sshd_config file and protect it from writing so you will have the original settings as a reference and to reuse as necessary. You can do this with the following commands:
sudo cp /etc/ssh/sshd_config /etc/ssh/sshd_config.original
sudo chmod a-w /etc/ssh/sshd_config.original
Check the OpenSSH server version
To check the version of the OpenSSH daemon installed:
Open the SSH port on the Firewall
If you need to have a switch connect to your laptop to copy files over SCP or you want to ssh back into the laptop you will need to allow SSH through the firewall.
The following command will allow SSH through the firewall from any IP address.
sudo ufw allow 22/tcp comment 'Open port ssh tcp port 22'
If you want to lock down to a specific IP and subnet, in this example the host 192.168.10.100 and subnet 192.168.20.0/24:
sudo ufw allow from 192.168.10.100 to any port 22
sudo ufw allow from 192.168.20.0/24 to any port 22 proto tcp
Verify the UFW firewall configuration
You can see that I have an IPv6 stack running. I use IPv6 in my home lab. I also have the syslog daemon installed on port 514 and I use GSConnect to communicate with my iPhone and Android phone on ports 1716-1764. Obviously I don't have a rule for SSH so let's add a UFW rule allowing SSH from any address.
When finished with SSH
You can either disable SSH and remove the rule or just disable SSH if you use it on a regular basis.
From the output above ssh is on lines 4 and 8. Once rule 4 is deleted, rule 8 will become rule 7!
An alias to start ssh and add the UFW rule
Here is the output of the alias command:
An alias to stop ssh and remove the ufw rule
Here is the output of the alias command:
References - OpenSSH Server
- How to Set Up and Use SSH in Linux
- How to open ssh 22/TCP port using ufw on Ubuntu
- How to delete a UFW firewall rule on Ubuntu
Yubico Authenticator
Yubico is one of the companies that makes Physical Security keys. These allow you to copy your private key to the Yubico and have access no matter what laptop you are on with just one key. It's beyond the scope of this guide but here are links to Yubico.
Brute Forcing SSH
I mentioned in the creating ssh keys section that usernames and passwords are easier to brute-force than keys are. You can use nmap to brute force ssh. In this example I created a file named users.lst and a file named pass.lst with valid user and passwords for the switch.
Obviously an attacker would be using a breach list or a social engineered list of names and passwords. But for demo purposes I didn't want to spend hours running nmap. I have a list of all the passwords that customers have given me over the years that I use in real situations.
I have had to use this method more than once at small school districts and other customers that don't have ISE or Clearpass and have used local creds. I also had to use this once at a Community College that had the network team arrested!
This should make it clear that you should set a limit on the number of login attempts!
General SSH References
- Upgrade your SSH keys! - In this post I'll demonstrate how to transition to an Ed25519 type of key smoothly, why you would want this and show some tips and tricks on the way there.
- Authenticating to Cisco devices using SSH and your RSA Public Key - Here is a blog post I did on setting up the network device to use ssh keys.
- Why you should be using scrypt for Cisco Router Password Storage
- SSH Command - Usage, Options, Configuration - SSH Academy tips and tricks
- sshd_config - How to Configure the OpenSSH Server? SSH Academy Tutorial on SSH server configuration
- Aruba CX ssh ciphers - The Aruba CX platform supports state of the art crypto!
- Arch wiki on ssh server Good information on OpenSSH including configuring Google Authenticator
- Arch wiki on ssh keys - As always, the Arch wiki has a great page on ssh
- The Ultimate Guide to SSH - Setting Up SSH Keys
