Haas Appliance Firewall

screenshot

The appliance is built on Ubuntu 24.04, one of the most secure operating systems available. Unlike a general-purpose server, the Raspberry Pi 5 appliance has limited functionality:

  • Transfer files to/from the Haas CNC control
  • Accept files from the CNC programmers
  • Connect to the Haas CNC controls using a predefined port and IP address to collect data
  • Allow management over ssh
  • Allow management with Cockpit

So we can lock it down using:

  • Local user accounts
  • Linux file permissions
  • Samba Server share permissions
  • The Ubuntu Uncomplicated Firewall (UFW)

Ubuntu 24.04 ships with OpenSSH 9.6, which has removed ssh-dss and made many other legacy protocols optional. You can verify the version using:

ssh -V
Command Output
OpenSSH_9.6p1 Ubuntu-3ubuntu13.14, OpenSSL 3.0.13 30 Jan 2024

Note

The instructions will walk you through step by step, but if you make a mistake, you could lock yourself out unless you have a keyboard and monitor connected or purchased the Serial cable

The project files

  • A systemd service to apply the firewall on boot
  • A systemd timer that will reapply the firewall rules daily
  • A script to verify the format of the csv file after editing
  • A custom Cockpit extension to manage the firewall

The combination of the systemd services, csv verification script, and Cockpit extension provides an easy to use, predictable configuration.

There is an installation script that copies the files to the correct locations and starts the services. The project also includes a script, configure_ufw_from_csv.sh to build and maintain the firewall configuration over time. Once the firewall is enabled, you should be able to pass a penetration test because:

  • The Samba shares are only exposed to the devices in the csv file
  • Ubuntu includes the latest version of Openssh
  • SSH access attempts are rate limited with ufw limit 22/tcp
  • The Cockpit management application is only exposed to the devices in the csv file with the management role

At the end of this section, there is a PowerShell script that you can use to test the security of the appliance.

The design concept of the configuration script

The design goal for the firewall configuration script is to provide an automated, error free, firewall configuration that is easy to modify as you add machines or users. Below is a description of the components:

  • An automated script reads a CSV file to build the firewall rules
  • Support for two roles:
    1. user → Samba (445) only
    2. Administrator → Samba (445), SSH (22), Cockpit (9090)
  • Adds UFW rules for IPv4 and IPv6 (UFW handles both automatically when IPv6 is enabled)
  • Adds extra firewall hardening that you may want in a manufacturing environment
  • Allows the Haas machines to be on a separate segmented subnet
  • Creates a log of the UFW changes

🟦 Why this design is good

  • Automatic appliance behavior via systemd
  • Developer‑friendly manual testing via CLI
  • No conflicts between the two methods: automatic/manual testing
  • No need to stop services to test

The CSV file format

The project includes a script, configure_ufw_firewall.sh that reads a csv file and creates the firewall rules. The csv file format is shown below:

username,desktop_ip_address,role
haas,192.168.10.143,Administrator
haassvc,192.168.10.104,user
mspadmin,192.168.10.120,Administrator
rgoodwin,192.168.10.120,Administrator
mchavez,192.168.10.133,Administrator

The csv file lives in the root of the Haas_Data_collect directory. This directory was shared as Haas. Once you map a drive, you can edit the file in Excel. Just remember to save it as a csv file, not an Excel file.

The available roles

User

  • Access to Samba shares (port 445) only

Administrator

  • Access to Samba shares (port 445)
  • SSH (22) access to manage the appliance
  • Cockpit (9090) access for web management

Haas Machine Tools

All Haas CNC machines authenticate using the haassvc account. The script can create rules to allow the CNC controls access to Samba from a dedicated subnet if your security policy requires segmentation.

Haas machines (haassvc)

  • Allowed from HAAS_MACHINES_SUBNET_V4 (and optionally v6) to 445/tcp
  • You can narrow or expand that subnet as your manufacturing network dictates.

In this example, the CNC machines are on 192.168.10.0/24:

192.168.10.0/24 → port 445

Modifying the Haas IP address range

If your machine tools are on a dedicated subnet

Additional security features

The script includes the following features in addition to the firewall allow/deny rules

NetBIOS is blocked

  • Explicitly denies 137/udp, 138/udp, 139/tcp so nothing revives that old stack by accident.

SSH hardening

  • Uses ufw limit 22/tcp to rate‑limit repeated connection attempts.

Safe defaults

  • deny incoming, allow outgoing
  • Loopback allowed

Script Options

Enabling a firewall while you are connected over ssh can lead to tears, especially if you are not on site! That's because the firewall will read the rules and execute them immediately. If you block ssh from the IP address of your management station you will lose connection. The dry-run mode previews the rules instead of applying them. Review the rules carefully!

If you applied the rules and just want to start over use reset mode to remove all rules at one time.

Dry Run Mode

Use --dry-run to preview all firewall changes without applying them.

Reset Mode

Use --reset to wipe all UFW rules and rebuild from the CSV.

Systemd Integration

The firewall is automatically applied at boot via:

haas-firewall.service

A daily sync is handled by:

haas-firewall.timer

Note

If you make a change to to the csv file and don't want to reboot or wait until the timer goes off you can run:

sudo systemctl start haas-firewall.service

Logs

All firewall actions are logged to:

/var/log/haas-firewall.log

Log rotation is configured to keep logs manageable.

Let's build the firewall system

Several files are needed to build the rules, run a timer to make sure the firewall is reapplied if disabled, and log the output. Below is where they are placed in the appliance:

/usr/local/sbin/
  configure_ufw_from_csv.sh

/home/haas/Haas_Data_collect/
  users.csv

/etc/systemd/system/
  haas-firewall.service
  haas-firewall.timer

/etc/logrotate.d/
  haas-firewall

Note

The script is stored in /usr/local/sbin which is a system level directory. The script should not need to be edited and to edit a file in /usr/local/sbin you need root privileges. You can use sudo nano /usr/local/sbin/configure_uft_from_csv.sh if you need to edit it.

The systemd files

In the root of the repository are the files needed to configure systemd. There is an installation script install_haas_firewall.sh that runs all of the commands below. If you want to fully understand how the firewall service works run the individual commands.

Automated installation of the Firewall Service

This script deletes configure_ufw_from_csv.sh after it copies it to /usr/local/sbin/. if you want to run it manually after the installation script use this command:

sudo /usr/local/sbin/configure_ufw_from_csv.sh

In the Haas_Data_Collect folder run the following:

sudo ./haas_firewall_install.sh

⭐ What this installer guarantees

  • No partial installs — it aborts safely if anything is missing
  • Script and validator are protected in /usr/local/sbin/
  • Systemd is configured correctly
  • Firewall rules apply at boot
  • Daily timer provides self‑healing
  • Customer directory stays clean (only users.csv remains)

If you want to uninstall the Firewall Service

🟦 Uninstaller Script (uninstall_haas_firewall.sh) This script safely removes:

  • The systemd service
  • The systemd timer
  • The installed scripts in /usr/local/sbin/
  • Reloads systemd

Leaves the CSV untouched

It also checks for file existence before removing anything.

Manual Installation

Copy the files to the correct location using

1
2
3
4
sudo cp haas-firewall.service /etc/systemd/system/
sudo cp haas-firewall.timer /etc/systemd/system/
sudo cp configure_ufw_from_csv.sh /usr/local/sbin/
sudo chmod +x /usr/local/sbin/configure_ufw_from_csv.sh

There is no output from these command.

Delete the script after copying

Once the configure_ufw_from_csv.sh file is copied to /usr/local/sbin we will delete it from the project directory. This is to prevent accidental changes being made.

1
ls -l /usr/local/sbin/configure_ufw_from_csv.sh

If the file exits in /usr/local/sbin, then delete the copy in the Haas_Data_collect directory:

1
rm /home/haas/Haas_Data_collect/configure_ufw_from_csv.sh

There is no output from this command.

Reload the daemons to incorporate the changes

sudo systemctl daemon-reload

There is no output from this command.

Enable and start the firewall Service

sudo systemctl enable haas-firewall.service
sudo systemctl start haas-firewall.service
systemctl status haas-firewall.service

Enable the timer

1
sudo systemctl enable --now haas-firewall.timer

There is no output from this command.

Verify the timer service:

1
systemctl list-timers | grep haas-firewall
Command Output
Need output

The bash script that creates the rules

In the root of Haas_Data_Collect is a script named configure_ufw_from_csv.sh and a csv file named users.csv. The script reads the data in a csv file and creates the Uncomplicated Firewall (UFW) rules.

make script executable. Run the following:

cd /home/haas/Haas_Data_collect/
chmod +x configure_ufw_from_csv.sh
ls -l configure*
Command Output
.rwxrwxr-x 4.8k haas 11 Jan 19:54  configure_ufw_from_csv.sh

The Dry-Run script option

The script lives in /usr/local/sbin/ so it requires root access to run it manually. During deployment is it possible to run it manually with the dry-run option using the following:

1
sudo /usr/local/sbin/configure_ufw_from_csv.sh --dry-run

Dry run mode reads the users.csv file, processes it and then displays what would be configured for UFW.

🟧 Why is there a dry-run mode? This is extremely helpful when:

  • testing new CSV formats
  • debugging customer issues
  • validating rule logic
  • verifying backups and validation

Here is what the output of the dry-run option looks like:

Command Output
[*] Setting UFW base policy...
[DRY-RUN] Would set IPV6=yes in /etc/default/ufw
[DRY-RUN] ufw default deny incoming
[DRY-RUN] ufw default allow outgoing
[DRY-RUN] ufw allow in on lo
[DRY-RUN] ufw allow out on lo
[DRY-RUN] ufw limit 22/tcp
[DRY-RUN] ufw deny 137/udp
[DRY-RUN] ufw deny 138/udp
[DRY-RUN] ufw deny 139/tcp
[*] Creating rules for Haas machines (haassvc)...
[DRY-RUN] ufw allow from 192.168.50.0/24 to any port 445 proto tcp comment 'Haas machines IPv4 -> Samba'
[*] Processing CSV: users.csv
[*] Adding ADMIN 'haas' from 192.168.10.143
[DRY-RUN] ufw allow from 192.168.10.143 to any port 445 proto tcp comment 'Admin haas -> Samba'
[DRY-RUN] ufw allow from 192.168.10.143 to any port 22 proto tcp comment 'Admin haas -> SSH'
[DRY-RUN] ufw allow from 192.168.10.143 to any port 9090 proto tcp comment 'Admin haas -> Cockpit'
[*] Adding USER 'haassvc' from 192.168.10.104
[DRY-RUN] ufw allow from 192.168.10.104 to any port 445 proto tcp comment 'User haassvc -> Samba'
[*] Adding ADMIN 'mspadmin' from 192.168.10.120
[DRY-RUN] ufw allow from 192.168.10.120 to any port 445 proto tcp comment 'Admin mspadmin -> Samba'
[DRY-RUN] ufw allow from 192.168.10.120 to any port 22 proto tcp comment 'Admin mspadmin -> SSH'
[DRY-RUN] ufw allow from 192.168.10.120 to any port 9090 proto tcp comment 'Admin mspadmin -> Cockpit'
[*] Adding ADMIN 'rgoodwin' from 192.168.10.120
[DRY-RUN] ufw allow from 192.168.10.120 to any port 445 proto tcp comment 'Admin rgoodwin -> Samba'
[DRY-RUN] ufw allow from 192.168.10.120 to any port 22 proto tcp comment 'Admin rgoodwin -> SSH'
[DRY-RUN] ufw allow from 192.168.10.120 to any port 9090 proto tcp comment 'Admin rgoodwin -> Cockpit'
[*] Adding ADMIN 'mchavez' from 192.168.10.223
[DRY-RUN] ufw allow from 192.168.10.223 to any port 445 proto tcp comment 'Admin mchavez -> Samba'
[DRY-RUN] ufw allow from 192.168.10.223 to any port 22 proto tcp comment 'Admin mchavez -> SSH'
[DRY-RUN] ufw allow from 192.168.10.223 to any port 9090 proto tcp comment 'Admin mchavez -> Cockpit'
[DRY-RUN] Would enable UFW
[DRY-RUN] Would show UFW status
[*] Done.

Custom csv file option

The default file name is users.csv. For testing, you can run a different csv file using the following:

sudo /usr/local/sbin/configure_ufw_from_csv.sh /path/to/test.csv

Cockpit Integration

Cockpit is a web-based graphical interface for servers, intended for everyone, especially those who are:

  • new to Linux (including Windows admins)
  • familiar with Linux and want an easy, graphical way to administer servers
  • expert admins who mainly use other tools but want an overview on individual systems

We’ll create a Cockpit plugin that shows a simple page with three actions:

  • Simulate Firewall Update (--dry-run)
  • Compare Current vs Planned Rules (--compare)
  • Rollback CSV from backup (prompts for backup filename)

Cockpit directory structure

/usr/share/cockpit/haas-firewall/ ├── manifest.json ├── index.html └── haas-firewall.js └── icon.png

Create the directory:

sudo mkdir -p /usr/share/cockpit/haas-firewall

copy the files

1
sudo cp /home/haas/Haas_Data_collect/cockpit/* /usr/share/cockpit/haas-firewall/

sudo cp manifest.json /usr/share/cockpit/haas-firewall/ sudo cp index.html /usr/share/cockpit/haas-firewall/ sudo cp haas-firewall.js /usr/share/cockpit/haas-firewall/

After placing these files, restart Cockpit:

sudo systemctl restart cockpit

Cockpit will pick it up automatically.

Restart Cockpit

sudo systemctl restart cockpit

Your new buttons will appear instantly.
