Let's build the appliance

screenshot

As you can imagine, there are a lot of steps required to build a functional appliance from scratch. But once you have completed it, you will have gained a lot of useful knowledge!

  • Clone the repository - This is how you get the code from the repository to the appliance.
  • Create the systemd service files - Used to start the Python data collection scripts when the appliance is booted.
  • Enable the systemd services - Configure the services to start on boot
  • Install Samba Server - Samba is used to create Windows compatible shares.
  • Create the security group - Used to allow Windows users access to the directory shares on the appliance.
  • Create the users - Multiple users are needed to deploy into production
  • Add the users to the security group - Required for sharing
  • Create the directories - A place to store files
  • Create the Samba shares - Allows Windows users to map a network drive to the appliance

The next sections will cover all of these topics in detail.

Clone the repository

Note

Linux uses a case sensitive file system. So Haas is different from haas. If you type a command, for example, LS -l instead of ls -l and it says

LS -l
zsh: command not found: LS

Make sure you have the case correct!

Open a terminal on the Pi

If you are using ssh to connect, you are already at the terminal. If you are using the desktop version of Ubuntu, press ctrl+alt+t to open a terminal.

  • Make sure you are in your home directory by running cd ~
  • Verify using pwd which is print working directory in Linux. You should see:
pwd
/home/haas

Note

The examples in this document will have /home/haas and /home/haas/Haas_Data_collect. When you install Ubuntu on your Raspberry Pi 5 use haas, all lowercase, as the username. If you use a different name, remember to update the path after you paste a command into the terminal.

  • Clone the repository using
git clone https://github.com/rikosintie/Haas_Data_collect.git
  • Change to the Haas_Data_collect folder using
cd Haas_Data_collect
  • List the files for reference using ls -l

The installation script

The repository includes a script named: haas_firewall_install.sh. The script does a lot of the heavy lifting to get the appliance up and running.

  • Writes the /etc/haas-firewall.conf file that allows you to add a custom subnet for the Haas CNCs if your network uses segmentation. Allows you to set a custom SSH port for the firewall rules if your security policy requires it.
  • Installs the systemd firewall service + timer
  • Installs Samba server and updates /etc/samba/smb.conf
  • Sets up Samba security and creates the "[Haas]" share
  • Creates Samba and Linux users from the initial_users.csv file
  • Installs the Cockpit extension for managing/monitoring the firewall
  • Installs the "micro" cli text editor
  • Installs the "fresh" cli text editor
  • Installs Python PIP
  • Installs the Linux "tree" command for listing directories and files.
  • Copies issue.net to /etc/issue.net (This is the Pre-logon banner)
  • Copies csvlens binary to /usr/local/sbin - csvlens is a cli tool for viewing csv files. Example csvlens users.csv
  • Creates the backup directory in the repo
  • Triggers an initial firewall configuration via systemd using the users.csv file.

It does NOT modify or delete anything inside the repo.

The installation script does not create the The systemd service files because they must be modified for your machine names and ip addresses. They are covered after the installation script.

Update text files

There are a three files in the Haas_Data_collect directory that need to be updated to fit your environment before you run the install script:

  • users.csv - This file contains usernames, ip addresses and roles for configuring the firewall.
  • initial_users.csv - Users who need access to the Windows shares on the appliance. The CNC controls will use the haassvc user account. Add CNC programmers, and operations personnel that need to copy files to/from the appliance.
  • issue.net - This is the login banner. It gets copied to /etc/issue.net by the haas-firewall-install.sh script. This is a generic file. Update it per your company's security policy.

These files are used as input to the haas-firewall-install.sh script that is presented next.

There two user components to the appliance setup, which may be confusing at first! The appliance is protected by the Ubuntu firewall. The firewall is configured automatically by the data in the file users.csv.

There are also users created from data in the file initial_users.csv. These are users that need to have both Linux and Samba accounts to access the file shares. The installation scripts creates the user accounts.

users.csv

This is a comma-separated value (csv) file that contains the users, ip addresses and roles of any users that need to access the Raspberry Pi 5 appliance. Every Haas CNC machine will need to be in this file, otherwise the firewall will block access. If your machines are on a dedicated IP subnet, a best practice, you can edit the /etc/haas-firewall.conf file and enter the subnet. There is a script that will read the haas-firewall.conf file and update the firewall. That is explained in the Cockpit management section.

The format for users.csv is:

username,ip_address,role
haas,192.168.10.143,Administrator
haassvc,192.168.10.104,user
mchavez,192.168.10.133,user
thubbard,192.168.10.100,user
st30,192.168.10.110,user
st30l,192.168.10.111,user
st40,192.168.10.112,user
vf2ss,192.168.10.113,user
vf5ss,192.168.10.114,user
minimill,192.168.10.115,user
  • username - The username of a person or machine that will access the appliance.
  • ip _address - This is the IP address of devices that need to access the appliance.
  • roles:
    1. Administrator - Users that can manage the appliance. They can access ssh, smb shares, Cockpit.
    2. User - This role is configured on the Haas CNC and any users that only needs to map drives. Only file share access through the firewall

Note

The username is used as a label in the firewall. Most users will map drives using the haassvc account. Below is an example of the firewall rules.

sudo ufw status numbered | sort -k5

     --                         ------      ----
     To                         Action      From
Status: active
[10] 445                        ALLOW IN    192.168.10.100             # thubbard-user-smb
[13] 9090                       ALLOW IN    192.168.10.223             # rgoodwin-admin-cockpit
[12] 445                        ALLOW IN    192.168.10.223             # rgoodwin-admin-smb
[11] 22                         ALLOW IN    192.168.10.223             # rgoodwin-admin-ssh
[ 6] 9090                       ALLOW IN    192.168.10.104             # toolroom-admin-cockpit
[ 5] 445                        ALLOW IN    192.168.10.104             # toolroom-admin-smb
[ 4] 22                         ALLOW IN    192.168.10.104             # toolroom-admin-ssh
[ 9] 9090                       ALLOW IN    192.168.10.113             # msp_admin-admin-cockpit
[ 8] 445                        ALLOW IN    192.168.10.113             # msp_admin-admin-smb
[ 7] 22                         ALLOW IN    192.168.10.113             # msp_admin-admin-ssh
[ 3] 9090                       ALLOW IN    192.168.10.143             # haas-admin-cockpit
[ 2] 445                        ALLOW IN    192.168.10.143             # haas-admin-smb
[ 1] 22                         ALLOW IN    192.168.10.143             # haas-admin-ssh

The users.csv file will remain in the Haas_Data_collection folder after the appliance is in production. Anytime the firewall needs to be modified you will update the users.csv file.

Use the following to edit the file if you are connected over ssh:

cd ~/haas/Haas_Data_collect
nano users.csv

When you are finished use the following to save and close the file:

ctrl+s
ctrl+x

Or use the micro text editor:

1
2
cd ~/haas/Haas_Data_collect
micro users.csv

When you are finished use the following to save and close the file:

ctrl+s
ctrl+q

If you are in the Desktop version of Ubuntu you can open the Files application and double click on users.csv. That will open the file in LibreOffice Calc. Make sure you save the file as a csv file and not an odf or excel format.

The initial_users.csv file

This is a comma-separated value (csv) file that contains usernames and passwords. These are users authorized to map drives to the appliance. Every user who needs to work with the appliance should be listed in this file. The installation script will create a Linux user account and Samba account for each user in initial_users.csv.

To create administrative users, say an admin for an MSP, use the Manage users by script to create the user.

User with only drive mapping permissions would include:

  • Haas CNC controls - Use haassvc on all machine tools when enabling file sharing. Their role in users.csv would be user.
  • CNC Programmers - You can map a drive using a Windows user name or use haassvc since the programmers only need to access the shares. Their role in users.csv would be user.
  • Operations employees - These are users that will be copying log files for data analysis. You can map a drive using a Windows user name or use haassvc since the programmers only need to access the shares. Their role in users.csv would be user.

There are two trains of thoughts on usernames

  1. Use haassvc for all CNC controls, programmers, and operations people. They only get r/w access to shares. They cannot manage the appliance.
  2. Use haassvc for all CNC controls, use the Windows username for all other users. They only get r/w access to shares. They cannot manage the appliance.

The first method is easier to deploy and maintain, but you lose the ability to track who has been logging in. The first method fits what Microsoft calls Tiered Administration.

How the Tier Model Segregates Accounts and Devices:

  • Tier 0 (Control Plane): This tier contains "crown jewel" assets like Domain Controllers and Identity Management Systems. Administrators must use a dedicated Tier 0 account and a hardened Privileged Access Workstation (PAW) to manage these systems.
  • Tier 1 (Management Plane): This tier consists of enterprise servers (e.g., SQL, Exchange, file servers). Admins use a separate Tier 1 account to manage these servers; this account is explicitly denied the right to log on to Tier 2 workstations.
  • Tier 2 (User Plane): This is the lowest tier, encompassing end-user workstations and devices. Users and Tier 2 admins use standard accounts here, which have no administrative rights on Tier 1 or Tier 0 systems.

The appliance can be considered a device, if you only use local Linux accounts like haas, haassvc, mspadmin even if the appliance was compromised, the attacker couldn't use the accounts to move laterally in Active Directory.

Key Principles

  1. Privilege Isolation: High-privileged credentials are never exposed to lower-tier systems, preventing attackers from moving laterally from Tier 2 to Tier 0.

  2. Clean Source Principle: All security dependencies must be as trustworthy as the object being secured, ensuring that administrative accounts are only used in appropriate contexts.

  3. Logon Restrictions: Interactive logons are restricted to the tier of the system being managed. For example, a Tier 0 admin should never log in interactively to a Tier 2 workstation.

By default, the only user who can run Linux commands with superuser rights is haas, the user who installed Ubuntu. Verify your company's security policy before deciding on a method to use.

I used xxxxxxxxx for the password in the initial_users file. This is because GitHub is scanned thousands of times per day by attackers looking for secrets. If I used anything resembling a password, attackers would be publishing my repository all over the dark web. I attended a Crowdstrike conference in Las Vegas in 2024. In one of the classes I got to enter rikosintie into their Dark Web tool. I was stunned that my repositories were listed as having ssh keys and passwords in the clear. None of the ssh keys or passwords were valid, I had changed several characters in the keys and the passwords were nonsense, but the Dark Web as very excited about them!

Here is the included sample file. Modify it to fit your environment:

username, password
haassvc, xxxxxxxxx

I know it's odd that there are users.csv and initial_users.csv but there is no secure way to leave passwords lying around in plain text files.

Warning

This file contains usernames/passwords that the installation script will use to create the Samba shares. You should delete this file as soon as the script finishes the installation.

Use the following to edit the file if you are connected over ssh:

cd ~/haas/Haas_Data_collect
nano initial_users.csv

When you are finished use the following to save and close the file:

ctrl+s
ctrl+x

Or use the micro text editor:

1
2
cd ~/haas/Haas_Data_collect
micro initial_users.csv

When you are finished use the following to save and close the file:

ctrl+s
ctrl+q

If you are in the Desktop version of Ubuntu you can open the Files application and double click on users.csv. That will open the file in LibreOffice Calc. Make sure you save the file as a csv file and not an odf or excel format.

The login banner - issue.net

screenshot

This is a text file that is displayed before a user logs in over ssh. The included file is a basic "You need Authorization" banner. Modify it to match your organization's security policy before running the installation script. If you need to update it later, use sudo nano /etc/issue.net to open the file. ASCII art is a method of making banners using ASCII characters. I used the ASCII Art Archive to create this banner. You can get much fancier if you want to spend the time! If you are also responsible for network equipment, you can use the approved banner from a switch or router.

                 Haas Data Collection Server

╔═════════════════════════════════════════════════════════════════╗
║                                                                 ║
║ UNAUTHORIZED ACCESS TO THIS NETWORK DEVICE IS PROHIBITED.       ║
║ You must have explicit permission to access or configure this   ║
║ device.  All activities performed on this device are logged and ║
║ violations of this policy may result in disciplinary action.    ║
║                                                                 ║
╚═════════════════════════════════════════════════════════════════╝

Use the following to edit the file if you are connected over ssh:

cd ~/haas/Haas_Data_collect
nano issue.net

When you are finished use the following to save and close the file:

ctrl+s
ctrl+x

If you are in the Desktop version of Ubuntu Open the Files application and right click on issue.net and select Open with text Editor. That will open the file in Gnome Text Editor.

Use the following to edit the file if you are connected over ssh:

cd ~/haas/Haas_Data_collect
sudo initial_users.csv

When you are finished use the following to save and close the file:

ctrl+s
ctrl+x

If you are in the Desktop version of Ubuntu you can open the Files application and double click on users.csv. That will open the file in LibreOffice Calc. Make sure you save the file as a csv file and not an odf or excel format.

The install script details

The installation script haas_firewall_install.sh is written in bash, the native Linux language for system administration tasks. I have included comments for every section. You should review the script before running it so that you have an idea what it does.

Use the following to view the file if you are connected over ssh:

cd ~/haas/Haas_Data_collect
cat initial_users.csv

If you are in the Desktop version of Ubuntu Open the Files application and right click on haas_firewall_install.sh and select Open with text Editor. That will open the file in Gnome Text Editor.

Run the installation script

In Linux, scripts have to be marked eXecutable before you can run them. The files should already have the execute bit set but check with:

cd ~/haas/Haas_Data_collect
ls -l haas_firewall_install.sh
Command Output
ls -l haas_firewall_install.sh
-rwxrwxr-x 1 mhubbard mhubbard 14347 Feb  5 15:12 haas_firewall_install.sh

If you don't see the x in the output, run the following:

chmod +x haas_firewall_install.sh

Execute the script using:

cd ~/Haas_Data_collect
./haas_firewall_install.sh

There will be a lot of output as the script does it's job! Once it completes, review the output for any error messages. I don't expect any failures, the script has been tested on a Raspberry Pi 5 with an NVME drive, an Intel NUC running Ubuntu Desktop, a virtual machine running ubuntu Desktop.

If there were no errors we can move on to creating the systemd service files that will automatically start the scripts when the Raspberry Pi 5 is booted.

The systemd service files

Ubuntu uses an initialization (init) service named systemd. Systemd manages what services are initialized when Ubuntu starts up. We will use systemd to manage the Python scripts.

The installation script Does Not copy any service files so the Python scripts to collect data are not running immediately after the installation script finishes.

The service files are where you define how to call the Python script when the Pi starts up. In the repository there are six files representing six different machine tools. A service file requires:

  • Machine name
  • The port to be used on the machine
  • The IP address of the CNC controller

Table of Machine

These are the machine names, ports and IP addresses in the sample files.

Machine Port# IP Address
ST40 5052 192.168.10.141
VF2SS 5053 192.168.10.142
VF5SS 5054 192.168.10.143
MINIMILL 5055 192.168.10.143
ST30 5056 192.168.10.144
ST30L 5057 192.168.10.145

You will have different names and IP addresses on your machine tools. No problem, just make a table of your names, the ports, and the IP addresses. Then modify the existing service files. Here is the format:

[Unit]
Description=Haas Python logger for ST40
After=network.target

[Service]
User=haas
WorkingDirectory=/home/haas/Haas_Data_collect/machines/st40
ExecStart=/usr/bin/python3 /home/haas/Haas_Data_collect/haas_logger2.py -a -t 192.168.10.140  --port 5052 --name ST40
Type=idle

[Install]
WantedBy=multi-user.target

Warning

Be extremely careful when you edit the files. Any mistake will prevent you from successfully receiving data from the machine and can be challenging to troubleshoot.

Creating systemd Service files

The systemd service files are located in /etc/systemd/system/ so you must use sudo to edit them. Think of sudo as UAC in Windows. The advantage is that you can proactively use sudo and not have to deal with pop up dialogs asking for permission!

As an example, let's use the included haas-st40.service file. You should be in the Haas_Data_collect directory. You can rename it using mv haas-st40.service new_name.service. Use the following to copy haas-st40.service to the /etc/systemd/system/ directory:

sudo cp haas-st40.service /etc/systemd/system/haas-st40.service or sudo cp new_name.service /etc/systemd/system/new_name.service

Use the following to edit the haas-st40.service file after you copy it:

sudo nano /etc/systemd/system/haas-st40.service

This will open haas-st40.service in the built in nano editor.

Note

For whatever reason, nano doesn't use the normal text editor keys. If you are brand new to Linux, use this tutorial to learn nano - The beginners guide to Nano the Linux command line text editor

The Fresh Editor is installed if you used the installation script. The homepage for the Fresh Editor is Fresh. I find it easier to use than nano because it uses the same key bindings as most GUI editors.

If you installed the desktop version of Ubuntu, you can use the GUI Gnome Text Editor GUI to edit the files by running:

sudo gnome-text-editor /etc/systemd/system/haas-st40.service

What you need to modify

  • Description - The description is shown when you check the status of the service. Change to something that makes sense in your environment
  • ExecStart - This is where the table of names, ports, IP addresses comes in handy.

Nothing else needs to be changed in the service file.

Configuring systemd to use the service files

Once you have the service file modified, use the following commands to set up the service:

sudo systemctl daemon-reload
sudo systemctl enable haas-st40.service
sudo systemctl start haas-st40.service

There is no output from these commands.

What the commands do

  • sudo systemctl daemon-reload - Forces systemd to read the changes in the systemd files
  • sudo systemctl enable haas-st40.service - Tells systemd to run the service on boot
  • sudo systemctl start haas-st40.service - Actually starts the systemd service

Once these commands are run the haas-st40.service should be active.

Run this command to check the status of the haas-st40.service:

sudo systemctl status haas-st40.service
Status of the haas-st40.service
╭─haas@haas ~
╰─$ sudo systemctl status haas-st40.service
● haas-st40.service - Haas Python logger for ST40
     Loaded: loaded (/etc/systemd/system/haas-st40.service; enabled; preset: enabled)
     Active: active (running) since Mon 2025-12-29 16:09:45 PST; 2s ago
   Main PID: 115518 (python3)
      Tasks: 1 (limit: 4601)
     Memory: 6.9M (peak: 7.1M)
        CPU: 37ms
     CGroup: /system.slice/haas-st40.service
             └─115518 /usr/bin/python3 /home/haas/Haas_Data_collect/haas_logger2.py -a -t 192.168.10.122 --port 5052 --name ST40

Dec 29 16:09:45 ubuntu-server systemd[1]: Started haas-st40.service - Haas Python logger for ST40.

Notice the description from the service file is shown. Also, Main PID can be useful during troubleshooting. That is the Process ID, similar to what you would see in the Windows Task Manager. In this case it's 115518 and we can track it using:

ps -ef | grep -E "115518|PID"
Command Output
UID          PID    PPID  C STIME TTY          TIME CMD
haas  115518       1  0 06:28 ?        00:00:04 /usr/bin/python3 /home/haas/Haas_Data_collect/haas_logger2.py -a -t 192.168.10.122 --port 5052 --name ST40

The haas is the User ID (UID) that owns the process, 115518 is the Process ID (PID).

Memory Usage

The status command also lists the amount of RAM used by the script. You can see that the peak usage was 7.1MB. I haven't seen the script use more than that, so a Raspberry Pi 5 with 8GB of RAM could support many machine tools. For an Intel physical or Virtual appliance 8GB RAM should also be sufficient.

Display the services

It's useful during troubleshooting to see a list of the services that systemd has running. Use the following to display themL

1
systemctl list-unit-files --type=service | grep enabled

That will return a long list of services. If you named your files starting with haas you can get a short list using:

1
systemctl list-unit-files --type=service | grep haas

Scaling up

If you only have a handful of machines, editing the included service files and changing the name of the systemctl commands is the quickest way to create the service files and enable the services.

If you have double or triple digits of machines, that gets old fast. You can use the Python script, conf-gen_xlsx_v1.py included in the repository, and a spreadsheet to generate the files and systemd commands automatically.

It's probably easier to clone the repo to your laptop and run the scripts on it. The script will run on Mac/Linux/Windows and you can create the spreadsheet on the laptop. Or just create the spreadsheet on the laptop and copy it to the appliance after the Samba shares are created.

The spreadsheet name is machines.xlsx. The format of the spreadsheet is that row one is a header with the following data:

description, username, ip_address, port, name

Fill out as many rows as you need, save it in the root of the Haas_Data_collect folder.

Here is a example:

description - username ip_address name
Logger for ST40 haas 192.168.0.140 st40
Logger for ST30 haas 192.168.0.141 st30
Logger for ST30L haas 192.168.0.142 st30l

Install Dependencies

The script requires some dependencies. Use the following to install them:

python3 -m pip install pandas
python3 -m pip install jinja2
python3 -m pip install openpyxl

Create the service files

Run the following:

python3 conf-gen_xlsx_v1.py -f machines.xlsx -t service-template.txt

This creates the service files and saves them as <name>.service to the root of the project. Note that you can name the spreadsheet anything you want. Just change the machines.xlsx to the new filename.

Create the sudo commands

Run the following: python3 conf-gen_xlsx_v1.py -f machines.xlsx -t systemd-template.txt

The files are saved as <name>.txt in the root of the project directory. Here are the contents of st40.txt

sudo cp haas-st40.service /etc/systemd/system/haas-st40.service
sudo systemctl daemon-reload
sudo systemctl enable haas-st40.service
sudo systemctl start haas-st40.service
sudo systemctl status haas-st40.service

# Create the directory for the share

mkdir /home/haas/st40

# Create the share configuration

[st40]
    comment = Logger for ST40
    path = /home/haas/st40
    read only = no
    browsable = yes
    writable = yes
    public = no
    valid users = @HaasGroup, haas # Ensure the user is valid
    force user = haas
    force group = HaasGroup
    create mask = 0664
    force create mode = 0664
    directory mask = 0775
    force directory mode = 0775

It's much easier to peer review a spreadsheet than a bunch of files! If the spreadsheet is accurate, you will instantly get the service files and the commands to install them.

Note

The template files are just text files formatted for Jinja2. Basically a set of curly braces like this represent a variable {{}}. You can create your own templates and run them. The Python script doesn't care what is in the template, it just reads the spreadsheet and renders the template.

I have a lot of Jinja2 resources on my Cisco DevNet github if you are interested.

Create aliases

During debugging you will find yourself typing the systemctl commands a lot. I recommend creating some bash aliases to cut down on the typing. Open the bashrc file on the Pi using nano ~/.bashrc or gnome-text-editor ~/.bashrc. If you are using zsh as your shell, the commands will be nano ~/.zshrc or gnome-text-editor ~/.zshrc

Note

Notice the period in front of the bashrc filename. In Linux/Unix the period at the front of a filename means it is a hidden file. To see hidden files use ls -la which means show all files.

Paste the following in at the bottom of the file:

alias gte='gnome-text-editor
alias dmr='sudo systemctl daemon-reload'
alias stop='(){sudo systemctl stop "$1".service}'
alias start='(){sudo systemctl start "$1".service}'
alias status='(){sudo systemctl status "$1".service}'
alias servfile='(){sudo nano /etc/systemd/system."$1".service}'

Save the file with ctrl+s, close it with ctrl+x Update bash by typing exec bash and pressing enter.

What does the $1 do

The $1 is a placeholder, it gets replaced with the first text on the command line after the alias name. For example stop st40 will become sudo systemctl stop haas-st40.service.

Use the aliases

Now you can type the following:

  • gte st30l.service instead of gnome-text-editor st30l.service
  • stop st40 to stop the haas-st40.service
  • start st40 to start the haas-st40.service
  • status st40 to show the status of the haas-st40.service
  • dmr to reload the daemons

Samba installation

Key changes:

  • Overwrites /etc/samba/smb.conf entirely with tee (without -a)
  • Backs up the original to smb.conf.backup first
  • Includes all the security settings in the [global] section
  • Disables the printer share
  • Adds testparm -s to validate the configuration before restarting
[global]
    workgroup = WORKGROUP
    server string = %h server (Samba, Ubuntu)
    log file = /var/log/samba/log.%m
    max log size = 10000
    logging = file
    panic action = /usr/share/samba/panic-action %d

    # Authentication
    server role = standalone server
    obey pam restrictions = Yes
    unix password sync = Yes
    passwd program = /usr/bin/passwd %u
    passwd chat = *Enter\snew\s*\spassword:* %n\n *Retype\snew\s*\spassword:* %n\n *password\supdated\ssuccessfully* .
    pam password change = Yes
    map to guest = Bad User

    # Protocol Security - Force SMB2/SMB3 only
    client min protocol = SMB2
    client max protocol = SMB3
    server min protocol = SMB2
    server max protocol = SMB3

    # Disable legacy protocols and services
    disable netbios = Yes
    disable spoolss = Yes

    # Disable printing
    load printers = No
    printing = bsd
    printcap name = /dev/null

    [printers]
    available = No
    browseable = No
    printable = Yes

[print$]
    available = No

    # Performance
    socket options = TCP_NODELAY IPTOS_LOWDELAY

[Haas]
    comment = Haas Directory Share
    create mask = 0664
    directory mask = 0775
    force create mode = 0664
    force directory mode = 0775
    force user = haas
    force group = HaasGroup
    path = /home/haas/Haas_Data_collect
    read only = No
    valid users = @HaasGroup haas
    browseable = yes

Security improvements in this config:

Forces SMB2 minimum (blocks SMB1 which has security vulnerabilities) Disables NetBIOS completely Disables printing services Only allows authenticated users (@HaasGroup)

This approach is cleaner and ensures no duplicate entries!
